Residential 4kw On Grid Solar Inverter Goodwe GW4000-SDT-20
Ask Latest Price
Video Channel
Brand Name :Goodwe
Model Number :GW4000-SDT-20
Certification :SAA / CE / ROHS / ISO9001 / CCC
Place of Origin :China
MOQ :10 units
Price :negotiable
Supply Ability :1000units/week
Packaging Details :carton package
Type :DC/AC Inverters
Phase :three Phase
Inverter Efficiency :98.8%
Input Voltage :180-1500V
Output Frequency :50/60Hz
Protection degree :IP65
Operating Altitude :4000(>3000 derating)
Operation Temperature Range :-30~60℃
User Interface :LED, Bluetooth+APP
PID recovery :optional
more
Contact Now

Add to Cart
Find Similar Videos
400W 405W 410W 415W Jinko PV Modules Tiger Neo N Type Monocrystalline Full Black 00:45
400W 405W 410W 415W Jinko PV Modules Tiger Neo N Type Monocrystalline Full Black
Bifacial Dual Glass Jinko PV Modules Tiger Neo N Type 78HL4-BDV 605-625W 00:42
Bifacial Dual Glass Jinko PV Modules Tiger Neo N Type 78HL4-BDV 605-625W
Jinko Tiger Neo N Type 78HL4-(V) 610-630 Watt Mono PV Module 00:30
Jinko Tiger Neo N Type 78HL4-(V) 610-630 Watt Mono PV Module
Bifacial LONGi PV Modules Half Cut Longi Solar 555W 535W 540W 545W 550W 00:39
Bifacial LONGi PV Modules Half Cut Longi Solar 555W 535W 540W 545W 550W
HPBC Black Frame Longi Hi-MO X6 Scientist 435W 440W Solar Panel 00:56
HPBC Black Frame Longi Hi-MO X6 Scientist 435W 440W Solar Panel
420W 430W Jinko Solar Panel Jinko Solar Tiger Neo N Type 425 W Black Frame 00:44
420W 430W Jinko Solar Panel Jinko Solar Tiger Neo N Type 425 W Black Frame
410W-430W Jinko Tiger Neo N Type Solar Photovoltaic Modules Monofacial 54HL4-(V) 00:40
410W-430W Jinko Tiger Neo N Type Solar Photovoltaic Modules Monofacial 54HL4-(V)
460W 465W Solar Photovoltaic Modules 470W 475W 480W Tiger Neo N Type 60HL4-(V) 00:39
460W 465W Solar Photovoltaic Modules 470W 475W 480W Tiger Neo N Type 60HL4-(V)
View Product Description

GW4000-SDT-20 Goodwe On Grid Inverter 4kW three phase on grid solar inverter residential solar inverter

Input 　 　 　 　 　 　 　 　 　 　
Max.Input Voltage (V) 1000 1000 1000 1100 1100 1100 800 1100 1100 1100
MPPT Operating Voltage Range (V) 180 ~ 850 180 ~ 850 180 ~ 850 140 ~ 950 140 ~ 950 140 ~ 950 140 ~ 650 140 ~ 950 140 ~ 950 140 ~ 950
Start-up Voltage (V) 180 180 180 180 180 180 180 180 180 180
Nominal Input Voltage (V) 620 620 620 620 620 620 370 620 620 620
Max. Input Current per MPPT (A) 16 16 16 15 15 30 30 30 30 30
Max. Short Circuit Current per MPPT (A) 20.0 20.0 20.0 18.7 18.7 37.5 37.5 37.5 37.5 37.5
Number of MPP trackers 2 2 2 2 2 2 2 2 2 2
Number of Strings per MPPT 1 1 1 1 1 2 2 2 2 2
Output 　 　 　 　 　 　 　 　 　 　
Nominal Output Power (W) 4000 5000 6000 8000 10000 12000 12000 15000 17000 20000
Nominal Output Apparent Power (VA) 4000 5000 6000 8000 10000 12000 12000 15000 17000 20000
Max. AC Active Power (W)*1 4400 5500 6600 8800 11000 13200 12000 16500 18700 22000
Max. AC Apparent Power (VA)*1 4400 5500 6600 8800 11000 13200 12000 16500 18700 22000
Nominal Output Voltage (V) 400, 3L / N / PE 　 380 / 400 / 415, 3L / N / PE 220 / 127,
3L / N / PE		 380 / 400 / 415, 3L / N / PE
Output Voltage Range (V) (according to local standard) 180 ~ 270 180 ~ 270 180 ~ 270 180 ~ 270 180 ~ 270 180 ~ 270 180 ~ 270 180 ~ 270 180 ~ 270 180 ~ 270
Nominal AC Grid Frequency (Hz) 50 / 60 50 / 60 50 / 60 50 / 60 50 / 60 50 / 60 60 50 / 60 50 / 60 50 / 60
AC Grid Frequency Range (Hz) 　 　 　 　 45 ~ 55 / 55 ~ 65 　 　 　 　
Max. Output Current (A) 6.4 8.0 9.6 12.8 16.0 19.1 31.9 24.0 27.1 32.0
Power Factor 　 　 　 ~1 (Adjustable from 0.8 leading to 0.8 lagging) 　 　 　
Max. Total Harmonic Distortion <3% <3% <3% <3% <3% <3% <3% <3% <3% <3%
Efficiency 　 　 　 　 　 　 　 　 　 　
Max. Efficiency 98.2% 98.2% 98.2% 98.3% 98.3% 98.4% 96.9% 98.4% 98.4% 98.4%
European Efficiency 97.6% 97.6% 97.6% 97.6% 97.6% 97.8% 96.4% 97.8% 97.8% 97.8%
Protection 　 　 　 　 　 　 　 　 　 　
PV Insulation Resistance Detection Integrated Integrated Integrated Integrated Integrated Integrated Integrated Integrated Integrated Integrated
Residual Current Monitoring Integrated Integrated Integrated Integrated Integrated Integrated Integrated Integrated Integrated Integrated
PV Reverse Polarity Protection Integrated Integrated Integrated Integrated Integrated Integrated Integrated Integrated Integrated Integrated
Anti-islanding Protection Integrated Integrated Integrated Integrated Integrated Integrated Integrated Integrated Integrated Integrated
AC Overcurrent Protection Integrated Integrated Integrated Integrated Integrated Integrated Integrated Integrated Integrated Integrated
AC Short Circuit Protection Integrated Integrated Integrated Integrated Integrated Integrated Integrated Integrated Integrated Integrated
AC Overvoltage Protection Integrated Integrated Integrated Integrated Integrated Integrated Integrated Integrated Integrated Integrated
DC Switch Integrated Integrated Integrated Integrated Integrated Integrated Integrated Integrated Integrated Integrated
DC Surge Protection 　 　 　 　 Type III (Type II Optional) 　 　 　
AC Surge Protection 　 Tpye III 　 　 　 Type III (Type II Optional) 　 　
AFCI Optional Optional Optional Optional Optional Optional Optional Optional Optional Optional
Emergency Power Off Optional Optional Optional Optional Optional Optional Optional Optional Optional Optional
Remote Shutdown Optional Optional Optional Optional Optional Optional Optional Optional Optional Optional
General Data 　 　 　 　 　 　 　 　 　 　
Operating Temperature Range (°C) -30 ~ +60 -30 ~ +60 -30 ~ +60 -30 ~ +60 -30 ~ +60 -30 ~ +60 -30 ~ +60 -30 ~ +60 -30 ~ +60 -30 ~ +60
Relative Humidity 0 ~ 100% 0 ~ 100% 0 ~ 100% 0 ~ 100% 0 ~ 100% 0 ~ 100% 0 ~ 100% 0 ~ 100% 0 ~ 100% 0 ~ 100%
Max. Operating Altitude (m)*2 4000 4000 4000 4000 4000 4000 4000 4000 4000 4000
Cooling Method 　 Natural Convection 　 　 Smart Fan Cooling 　
Display 　 　 　 LED, LCD (Optional), WLAN + APP 　 　 　
Communication 　 　 　 WiFi, RS485 or LAN or 4G (Optional) 　 　 　
Weight (kg) 15.0 15.0 15.0 20.5 20.5 23.5 26.0 26.0 26.0 26.0
Dimension (W × H × D mm) 354 × 433 × 147 415 × 511 × 175 　 415 × 511 × 198 　
Noise Emission (dB) <34 <34 <34 <25 <25 <50 <50 <50 <50 <50
Topology 　 　 　 　 Non-isolated 　 　 　 　
Self-consumption at Night (W) <1 <1 <1 <1 <1 <1 <1 <1 <1 <1
Ingress Protection Rating IP65 IP65 IP65 IP65 IP65 IP65 IP65 IP65 IP65 IP65
DC Connector 　 　 MC4 (4 ~ 6mm²) 　 　 　 　
AC Connector Plug and play connector 　 　 OT Terminal 　 　 　
*1: For Chile Max. AC Active Power (W) & Max. Output Apparent Power (VA): GW4000-SDT-20 is 4000, GW5000-SDT-20 is 5000, GW6000-SDT-20 is 6000, GW8000-SDT-20 is 8000, GW10K-SDT-20 is 10000, GW12K-SDT-20 is 12000, GW12KLV-SDT-20 is 12000, GW15K-SDT-20 is 15000, GW17K-SDT-20 is 17000, GW20K-SDT-20 is 20000.
*2: For Australia, Max. Operating Altitude (m) is 3000.
*: Please visit GoodWe website for the latest certificates.
*: All pictures shown are for reference only. Actual appearance may vary.
